STAR

Introduction

Printing Specifications
Printing Method	Direct thermal
Printing Resolution	203 dpi (8 dots per mm)
Printing Speed	Max.6inch/s（152mm/s）
Printing Width	Max 56mm
Paper width	Max 60mm
Emulation	ZPL, EPL, TSPL
Fonts/Characters/Bar Codes
Built-in font	GB18030, ASCII, 1D Barcode, QR Code
Connectivity	Standard : USB 2.0 Option : Dual-mode BT 4.0, IEEE 802.11 b/g/n WIFI, Ethernet port choose one of three
Software
Driver and Configuration Tool	Windows Vista/XP/7/8/8.1/10/11（32bit/64bit）
SDK	Android, IOS
Print Media
Type	Thermal web (continuous paper, label paper, Black Label Paper), thermal folding paper Direction of heat sensitive surface
Outer thickness	0.08~0.3mm
Inner diameter of coil core	No restrictions
Outside diameter of paper roll	127mm
Sensor Management
Standard sensors	Open sensor, paper sensor, label sensor, Paper Tear sensor, Black mark sensor
Physical Specifications
Dimensions	254113171mm
Weight	About 1.7 kg
Environmental Specifications
Operating condition	5~40℃ / 30~80%RH(non-condensing)
Storage condition	-10~50℃ / 10~90%RH(non-condensing)
Environmental Specifications

Operator Controls and Indicators
LED indicator	Three LED lights(green, red, red)
Key Only One key	Feed Buzzer None
Memory Capacity
Memory	SDRAM: 32M Flash: 8M
Receive buffer	256K bytes
Paper Feeding method
Feeding	Web, rear folding paper, external support into thepaper, external support intothe paper
Regulatory Approvals
Certification	CE, CCC
Options and Accessories
Option	Cutter(for receipt, label and wristband), peeler
